Monitoring Parameters

• ECG (3/5 lead standard, optional 6/12 lead)
• SpO2 (Oxygen Saturation)
• NIBP (Non-invasive Blood Pressure)
• EtCO2 (Sidestream CO2 – optional)
• Pulse Rate
• Respiration Rate

ECG Performance

• Advanced iSEAP™ algorithm for arrhythmia detection (up to 33 types)
• SEMIP™ algorithm validated by CSE, MIT & AHA databases
• Multi-lead analysis for higher accuracy
• Customizable lead placement (6-lead option available)

SpO2 Performance

• iMAT™ algorithm for motion tolerance & low perfusion accuracy
• Perfusion Index (PI) range: 0.05% – 20%
• High precision measurement (up to 0.01% accuracy in low ranges)
• Simultaneous SpO2 and NIBP measurement supported

NIBP (Blood Pressure)

• iFAST™ algorithm – quick measurement (~15 seconds)
• iCUFS™ smart cuff inflation/deflation system
• Automatic cuff size recognition
• Venipuncture assistance mode available

CO2 Monitoring (Optional)

• EDAN G2 Sidestream CO2 module
• iCARB™ algorithm for accurate waveform identification
• Low sampling rate: 50 ml/min
• Advanced water trap design for reliability
• Standard luer lock connectors (cost-efficient consumables)

System Features

• Fanless design (low noise & reduced dust accumulation)
• Compatible with up to 31 disinfectants (high durability)
• Built-in storage for patient data
• HDMI output support
• 5G Wi-Fi connectivity

Battery & Power

• Long battery life for transport use
• Energy-efficient system design
